Inverter Duty Motor Specification

Noise Level
Within permissible limits as per IS std.

Sealed Type
Totally Enclosed Fan Cooled (TEFC)

Standard
IS 325, IEC 60034

Efficacy
IE2 / IE3 Efficient

Starting Type
Star-Delta / DOL

Horse Power
Standard range: 0.5 HP to 480 HP

Bearing Type
Deep groove ball bearing

Power Rating
Up to 355 kW

Torque
Constant torque with VFD

Pressure
Atmospheric

Rated Frequency
50/60 Hz

Cooling Method
Fan cooled

Rated Voltage
415 V

Current Type
AC

Ambient Temperature
-20C to +50C

Voltage
415 V AC (standard), 380-480 V available

Motor Type
Inverter Duty Induction Motor

Poles Number
2, 4, 6, or 8 Poles

Features
Low vibration, low noise, robust construction, suitable for VFD operation

Product Type
Inverter Duty Motor

Output Power
As per application requirement (commonly ranges from 0.37 kW to 355 kW)

Frequency (MHz)
50/60 Hz

Protect Feature
Overload protection, insulation

Phase
Three Phase

Speed
Typically 750-3600 RPM (variable with inverter)

Power
As per rating plate (varies by model)

Color
Blue / Customized

Dimension (L*W*H)
Depends on output power rating

Weight
Varies as per model & specification

Shaft Diameter
As per IEC/IS standards by frame size

Mounting Type
Foot Mounted / Flange Mounted

IP Rating
IP55 / IP56 (on request)

Paint Finish
Epoxy coating for corrosion resistance

Application
Suitable for Pumps, Fans, Conveyors, Crushers, Compressors, Machine Tools, Industrial Automation

Thermal Protection
PTC Thermistor available on request

Service Factor
1.15 - 1.25

Lubrication
Grease packed, sealed for life (optional)

Duty Cycle
S1 (Continuous Duty)

Environmental Compliance
RoHS Compliant

Power Factor
Typically 0.8 to 0.95

Frame Material
High Grade Cast Iron / Aluminum

Frequency Range
5 - 100 Hz (as per VFD operation)

Insulation Class
Class F (with Class B Temp. Rise)

Cable Entry
Double Cable Entry (on terminal box)

Vibration Level
As per IS/IEC Standards

About Inverter Duty Motor

Experience an extraordinary blend of performance and reliability with our acclaimed Inverter Duty Motor, offered at an unbeatable price. This highly in-demand motor features superb construction using high-grade cast iron or aluminum frames and is designed for continuous S1 duty. The inclusion of Class F insulation, advanced overload protection, and corrosion-resistant epoxy coating ensures operational longevity. Achieving IE2/IE3 efficiency, it delivers consistent torque-even under VFD applications. Its adaptability for pumps, conveyors, fans, and machine tools makes it the preferred choice across industries. RoHS compliance and robust, engineered design round out this spectacular solution for industrial automation.

Superb Features and Versatile Application

Our Inverter Duty Motor is built with advanced features such as low vibration, sealed-for-life lubrication (optional), and overload protection. The machine's robust TEFC construction ensures operational stability on various application surfaces, including pumps, fans, crushers, and conveyors. Designed for ease of installation, its foot or flange mounting and double cable entry make it ideal for machine tools and industrial automation where continuous operation and reliability are paramount.

Dispatched with Care: Market Reach and Logistics

Dispatched efficiently from our main domestic market in India, these motors are available at a competitive sale price. They are commonly shipped from key FOB ports, ensuring prompt transportation to any required location. Sample units are made available for evaluation before bulk orders, further supporting client confidence. Our reliable distribution process guarantees you receive quality motors that meet industrial demands without delay or complications.

FAQ's of Inverter Duty Motor:

Q: How does the Inverter Duty Motor ensure reliable performance under varying loads?

A: The Inverter Duty Motor is designed with constant torque characteristics and robust insulation, maintaining superb efficiency and reliability under diverse load conditions-even at varying speeds via VFD operation.

Q: What are the typical applications for this Inverter Duty Motor?

A: This motor is ideal for a wide range of applications, including pumps, fans, conveyors, crushers, compressors, machine tools, and industrial automation-essentially wherever variable speed and continuous duty are vital.

Q: Where can these inverter duty motors be dispatched from?

A: The motors are typically dispatched from major FOB ports in India and delivered efficiently to domestic or international markets, ensuring prompt and safe transportation.

Q: When should overload protection and thermal sensors be requested?

A: Overload protection is built in, while PTC thermistor thermal protection is available on request-recommended for demanding environments where additional safeguards are desired.

Q: What are the main benefits of the epoxy paint finish and robust frame material?

A: The epoxy paint offers superb corrosion resistance, while high-grade cast iron or aluminum frames provide remarkable durability, ensuring a long service life even in harsh industrial conditions.
